DIY Vibratory Tumbler

DIY Vibratory Tumbler

Regular price $0.00 USD
Regular price Sale price $0.00 USD
Sale Sold out

The Ultimate Tumbler Kit!

These plans will allow you to build your own vibratory tumbler for about 1/2 the cost of buying one. All of the components are readily available which means you can get to building it in only a matter of days!

As part of our mission to "Support American Innovators", we're giving these plans away for FREE! My only ask is that you share this with someone who could also benefit from these plans... Thank you!

The Deets:

  • 32" wide, 12" deep, & 13" tall
  • Tumbler motor is self contained & sealed... zero maintenance!
  • Uses a VFD drive, so you get the convenience of a wall outlet with 3-phase performance! This also allows control over motor direction and rotation speed.
  • Unit uses rubber bushings instead of springs for quiet operation!
  • Tub uses a UHMW liner... Long Lasting
  • NO custom parts! All off the shelf components (minus the fabricated metal parts)

Again... These plans are FREE!

But, if you don't have the means to build one of these we also offer them as a Sheet-Metal Kit! All you'll need to do is weld the parts together and purchase/assemble the parts from the parts list!
You'll get the following items with the Sheet-Metal Kit:

  • All 11 gauge parts, cut & bent (including the "bump-formed" tub)
  • All 3/16 parts, cut & bent
  • Packed in 2x boxes and shipped via UPS ground!

Due to popular request! We are also offering the Tub-Only Kit - this will be just the bump formed tub (the hardest part to bend).

** Side Note: The total cost to build this kit will vary. But the typical range is $1,900 to $2,200 depending on variables like shipping... This does not include any media for the tumbler... **
